decoder.h File Reference

Declaration of the mad_decoder structure and methods, the core of libmad library. More...

#include "stream.h"
#include "frame.h"
#include "synth.h"
#include "callbacks.h"

Include dependency graph for decoder.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	mad_decoder
	This holds all information about how you want your stream decoded, such as input/output functions, error handling functions, etc. More...
Defines
#define	mad_decoder_options(decoder, opts)   ((void) ((decoder)->options = (opts)))
Enumerations
enum	mad_decoder_mode { MAD_DECODER_MODE_SYNC = 0, MAD_DECODER_MODE_ASYNC }
enum	mad_flow { MAD_FLOW_CONTINUE = 0x0000, MAD_FLOW_STOP = 0x0010, MAD_FLOW_BREAK = 0x0011, MAD_FLOW_IGNORE = 0x0020 }
Functions
void	mad_decoder_init (struct mad_decoder *decoder, void *data, input_callback input_func, header_callback header_func, filter_callback filter_func, output_callback output_func, error_callback error_func, message_callback message_func)
	initialize a decoder object with callback routines.
int	mad_decoder_finish (struct mad_decoder *)
int	mad_decoder_run (struct mad_decoder *, enum mad_decoder_mode)
	run the decoder thread either synchronously or asynchronously.
int	mad_decoder_message (struct mad_decoder *, void *, unsigned int *)
	send a message to and receive a reply from the decoder process.

---

Detailed Description

Declaration of the mad_decoder structure and methods, the core of libmad library.

Definition in file decoder.h.

---

Define Documentation

#define mad_decoder_options	(	decoder,
		opts		)	((void) ((decoder)->options = (opts)))

Definition at line 87 of file decoder.h.

---

Enumeration Type Documentation

enum mad_decoder_mode

Enumerator:

MAD_DECODER_MODE_SYNC
MAD_DECODER_MODE_ASYNC

Definition at line 33 of file decoder.h.

enum mad_flow

Enumerator:

MAD_FLOW_CONTINUE	continue normally
MAD_FLOW_STOP	stop decoding normally
MAD_FLOW_BREAK	stop decoding and signal an error
MAD_FLOW_IGNORE	ignore the current frame

Definition at line 38 of file decoder.h.

---

Function Documentation

int mad_decoder_finish

(

struct mad_decoder *

)

Definition at line 90 of file decoder.c.

References mad_decoder::async, mad_decoder::in, MAD_DECODER_MODE_ASYNC, mad_decoder::mode, mad_decoder::out, and mad_decoder::pid.

Referenced by decode().

void mad_decoder_init	(	struct mad_decoder *	decoder,
		void *	data,
		input_callback	input_func,
		header_callback	header_func,
		filter_callback	filter_func,
		output_callback	output_func,
		error_callback	error_func,
		message_callback	message_func
	)

initialize a decoder object with callback routines.

Definition at line 62 of file decoder.c.

References mad_decoder::async, mad_decoder::cb_data, mad_decoder::error_func, mad_decoder::filter_func, mad_decoder::header_func, mad_decoder::in, mad_decoder::input_func, mad_decoder::message_func, mad_decoder::mode, mad_decoder::options, mad_decoder::out, mad_decoder::output_func, mad_decoder::pid, and mad_decoder::sync.

Referenced by decode().

int mad_decoder_message	(	struct mad_decoder *	,
		void *	,
		unsigned int *
	)

send a message to and receive a reply from the decoder process.

Definition at line 561 of file decoder.c.

References mad_decoder::async, mad_decoder::in, MAD_DECODER_MODE_ASYNC, MAD_FLOW_CONTINUE, mad_decoder::mode, and mad_decoder::out.

int mad_decoder_run	(	struct mad_decoder *	,
		enum	mad_decoder_mode
	)

run the decoder thread either synchronously or asynchronously.

Definition at line 526 of file decoder.c.

References MAD_DECODER_MODE_ASYNC, MAD_DECODER_MODE_SYNC, mad_decoder::mode, run_sync(), and mad_decoder::sync.

Referenced by decode().

Here is the call graph for this function:
